NETSCOUT LRAT-2000-KIT LinkRunner AT & IntelliTone Pro Copper Fiber Ethernet Network Test Kit
Description
Product Features
- Portable troubleshooting device for analyzing and testing Ethernet networks over copper and fiber optic cable infrastructure
- Stores and performs automated connectivity tests to help identify and analyze network problems
- Analyzes copper or fiber cabling infrastructure, verifies connections at 10M/100M/1G, validates power over Ethernet (PoE) performance, and discovers VLAN ports and switches to help identify potential issues
- Measures the availability and responsiveness of network services, including DHCP and DNS, to diagnose and solve complex issues
- Includes the IntelliTone Pro 200 probe for detecting IntelliTone digital signals and 500 to 1,200 Hz analog signals to locate, trace, and isolate copper cabling
Product Specifications
| Brand Name | NETSCOUT |
|---|---|
| EAN | 0013269005204 , 0754082091325 , 0779184005148 |
| Included Components | Other Networking Devices |
| Item Weight | 1.12 pounds |
| Material | Not Applicable |
| Model Number | LRAT-2000-KIT |
| Number of Items | 1 |
| Part Number | LRAT-2000-KIT |
| Size | LRAT-2000-KIT |
|---|---|
| Specific Uses For Product | personal |
| Specification Met | No |
| Style | LinkRunner AT & IntelliTone Pro Copper Fiber Ethernet Network Test Kit |
| UNSPSC Code | 43222643 |
| UPC | 779184005148 , 013269005204 , 754082091325 |
| Warranty Description | Not Applicable |
From the manufacturer
NETSCOUT LRAT-2000-KIT LinkRunner AT Network Auto-Tester Extended Test Kit
The NETSCOUT LinkRunner AT Network Auto-Tester is the fastest way to solve network connectivity problems. This rugged, handheld network tester takes the guesswork out of troubleshooting with its complete one-button AutoTest. The AutoTest performs your required set of connectivity tests in 10 seconds, enabling you to accurately and quickly identify and solve network problems. The extended test kit adds accessories to increase troubleshooting capabilities.
AutoTest accurately identifies network problems in 10 seconds
With a three-second boot-up and a one-button AutoTest that performs a customized set of connectivity tests in ten seconds, the LinkRunner AT enables quick and accurate problem identification to solve network problems fast. The AutoTest includes TruePower Power over Ethernet measurement, negotiation of link speed and duplex, discovery of switch port and VLAN information, negotiation of IPv4 and IPv6 addresses, availability of the gateway and the DNS servers, and the connection to user-defined devices and TCP applications. Save and share AutoTest profiles to standardize the troubleshooting process and create best practices.
Test twisted pair and fiber optic Ethernet links at Gigabit rates
Troubleshoot copper and fiber links with the integrated 10/100/Gig copper RJ45 and 100/Gig fiber optic SFP interfaces. Test twisted pair cables for length, shorts, opens or split pairs with a remote cable identifier, the built-in wiremap port or on non-terminated cables. Test fiber optic cables for continuity and received power. Digital and analog cable toning and switch port light blinking help locate and identify twisted pair cables. The office locator kit allows identification of up to six different RJ45 jacks.
Discover the nearest switch and VLAN
Using discovery protocol analysis (LLDP, CDP or EDP) the LinkRunner AT tester identifies the nearest switch and the VLAN IDs. Nearest switch information includes switch name, model, IP address, port/slot, speed/duplex (actual and advertised), signal strength, connection type (MDI or MDI/X), PoE voltage and power (actual and test limit), and a graphical representation of power on pairs.
Document test results
Run the LinkRunner Manager application to transfer saved test results from the tester to a Windows PC. Generate customize reports to close trouble tickets, escalate problems and prove acceptable connectivity. Use the management application to create and manage AutoTest profiles and to upgrade tester firmware.
Kit extends testing capabilities
LinkRunner AT LRAT-2000-KIT adds the following accessories: WireView cable identifiers #2 - #6, an IntelliTone 200 Probe and a LinkRunner AT holster – all packaged in a deluxe carrying case. The WireView cable identifiers are used for identification of cable runs where the work area outlets are mislabeled or unlabeled. The IntelliTone 200 probe detects digital and analog signals generated by the LinkRunner AT tester to locate and isolate twisted pair cabling.
What's in the Box?
- LinkRunner AT 2000 Network Auto-Tester
- Rechargeable lithium-ion battery pack
- AC power adapter and line cord
- WireView Cable IDs #1 - #6
- RJ45 coupler
- USB cable
- Holster
- CD with LinkRunner Manager PC application
- IntelliTone 200 Probe
- Getting started guides
- Deluxe carrying case
Product description
The NETSCOUT LinkRunner AT Network Auto-Tester is the fastest way to solve network connectivity problems. This rugged, handheld network tester takes the guesswork out of troubleshooting with its complete one-button Auto Test. The Auto Test performs your required set of connectivity tests in 10 seconds, enabling you to accurately and quickly identify and solve network problems. The extended test kit adds accessories to increase troubleshooting capabilities.
Product detailsSize: LRAT-2000-KIT
|
